XL-3216PDC is a 1206-packaged phototransistor, measuring 3.2×1.6×0.8mm with a black colloid. Compliant with ROHS and MSL Grade 3, it’s suitable for SMT automatic production and reflow soldering. Operating and storage temperature ranges are -40~+85℃, with 2000V ESD protection. It has a peak sensitive wavelength of 880nm and photocurrent of 300-600μA (compatible with 850nm/940nm infrared light). Soldering requires reflow 260℃≤6s or manual 300℃≤3s. Ideal for intelligent appliance iris recognition, infrared luminescent micro light barriers, photoelectric switches, smoke detectors, etc.
Outline Dimensions (L / w / h): 3.2 x 1. 6 x 0.8 mm
Colloid:black colloid
Environmental protection products Complied With ROHS Directive
Moisture sensitivity level（MSL） : 3 levels
EIA standard packaging
Suitable for SMT automatic production
Suitable for infrared reflow soldering process
Intelligent product household appliance iris recognition；
Infrared luminescent micro light barrier
floppy disk driver
Photoelectric switch
Smoke Detector
infrared sensor
Induction switch
