The XL-D76763SURC is a red LED with a through-hole piranha-style package, featuring an F3 dome-shaped (round head) design. Its size is 7.6×7.6×2.5×3.0mm (shorter in height than the F5 model, saving vertical space). It uses a clear epoxy and meets ROHS environmental standards, with a moisture sensitivity level of MSL 2. This LED has low power consumption and drive current (200mW/60mA), while offering high brightness (typical 6000mcd) and a 120° beam angle, achieving good brightness at low power. It's perfect for indicator and lighting applications where space is tight but strong light is needed.
Optical Performance:
Emitting Color: Red (transparent colloid, F3 round-top package)
Dominant Wavelength (λd): 615~635nm (typical peak wavelength 625nm)
Luminous Intensity (IV): 4000~6000mcd (@60mA, typical 6000mcd)
Viewing Angle (2θ1/2): 120° (between F5 round-top 90° and flat-top 140°, balancing brightness and coverage)
Spectral Width (Δλ): 20nm (typical)
Electrical Parameters (Ta=25℃):
Power Consumption: 200mW
Maximum Forward Current (IF): 60mA
Forward Pulse Current (IFp): 240mA
Forward Voltage (VF): 1.8~2.4V (@60mA)
Reverse Current (IR): ≤10μA (VR=5V)
Environment & Reliability:
Operating Temperature: -20℃ ~ 85℃
Storage Temperature: -40℃ ~ 85℃
Soldering Heat Resistance: Wave soldering 240℃ ≤ 6s, Manual soldering 300℃ ≤ 3s, solder joints should be at least 2.0mm above the bottom of the colloid
Passed 1000-hour lifespan test, high temperature and humidity (85℃/RH 85~90%), thermal cycling (-40℃~100℃), thermal shock (-45℃~105℃), and lead bending reliability tests
Others:
EIA standard moisture-proof and anti-static bag packaging
Supports brightness, voltage, and wavelength sorting, making batch consistency selection easy
Outdoor Signage & Lighting: Backlights for advertising light boxes, large-font luminous modules, outline lights for city buildings, outdoor displays; suitable for red lights in traffic signals, with a 120° angle for multi-directional visibility, and a shorter height for more compact designs.
Industrial & Public Facilities: Status indicator lights for industrial equipment, emergency lighting, commercial lighting, and indoor plant supplemental lighting.
Consumer Electronics & Home Appliances: Decorative light strips for home appliances, work status indicator lights (F3 low-profile design is good for slim devices).
Automotive Lighting: Can be used for dashboard backlighting, interior indicator lights, brake lights, turn signals, etc. (bright enough and space-saving with lower height).
