The XL-D7676SURC is a red LED with a straight-in piranha package (flat top), measuring 7.6×7.6×2.5mm in size (shorter in height compared to the round-top version). It uses a clear resin and meets ROHS environmental standards, with a moisture sensitivity level of MSL 2. This LED features an ultra-wide beam angle of 140°, making it great for situations that need uniform lighting over a large area. Plus, it has low power consumption and drive current (200mW/60mA), making it ideal for energy-conscious indicator and backlight applications.
Optical Performance:
Light Color: Red (transparent colloid, flat-top package)
Peak Wavelength (λd): 615~635nm (typical peak 625nm)
Luminous Intensity (IV): 2000~3000mcd (@60mA)
Viewing Angle (2θ1/2): 140° (extra wide angle, better than conventional 90° models)
Spectral Half-Width (Δλ): 20nm (typical)
Electrical Parameters (Ta=25℃):
Power Consumption: 200mW (lower than 0.5W models)
Max Forward Current (IF): 60mA
Forward Pulse Current (IFp): 240mA
Forward Voltage (VF): 1.8~2.4V (@60mA)
Reverse Current (IR): ≤10μA (VR=5V)
Environment and Reliability:
Operating Temperature: -20℃~85℃
Storage Temperature: -40℃~85℃
Soldering Heat Resistance: Wave soldering 240℃ ≤6s, manual soldering 300℃ ≤3s, solder joint must be at least 2.0mm above the bottom of the colloid
Passed 1000-hour lifespan test, high temperature & high humidity (85℃/RH 85~90%), thermal cycling (-40℃~100℃), thermal shock (-45℃~105℃), and lead bending reliability tests
Others:
Packaged in EIA standard moisture-proof and anti-static bags
Supports screening by brightness, voltage, and wavelength to make batch selection consistent
Outdoor Signage and Lighting: Backlights for advertising lightboxes, large-character luminous modules, contour lights for city buildings, outdoor display screens; especially suitable for backlighting or contour lighting scenarios that require wide-angle, even light output.
Industrial and Public Facilities: Status indicator lights for industrial equipment, emergency lighting, commercial lighting, indoor cultivation supplemental lighting.
Consumer Electronics and Home Appliances: Decorative light strips for home appliances, work status indicator lights (flat-head design allows softer light and wider coverage).
Automotive Lighting: Can be used for dashboard backlighting, interior ambient lights, and other places that require a wide light angle (main lights like brake lights and turn signals are slightly less bright and need to be evaluated according to actual light intensity requirements).
