XL-1606PDC is a 0602-packaged phototransistor, measuring 1.6×0.6×1.1mm with a black colloid. Compliant with ROHS and MSL Grade 3, it’s suitable for SMT automatic production and reflow soldering. Operating and storage temperature ranges are -40~+85℃, with 2000V ESD protection. It has a peak sensitive wavelength of 880nm and photocurrent of 300-600μA (compatible with 850nm/940nm infrared light). Soldering requires reflow 260℃≤6s or manual 300℃≤3s. Ideal for medical equipment, infrared remote controls, camera monitors, industrial control, etc.
Outline Dimensions (L / w / h)：1.6 x 0.6 x 1.1mm
Colloid：black colloid
Environmental protection products Complied With ROHS Directive
Moisture sensitivity level（MSL）： 3 levels
EIA standard packaging
Suitable for SMT automatic production
Suitable for infrared reflow soldering process
Medical equipment
Infrared remote controller
Camera monitoring head
Industrial control: counters, thermal imaging, smart meter
Infrared photoelectric switch
Wireless communication and signal transmission
Intelligent car, robot
