XL-ALS-PDIC2016C is a color light sensor with color temperature and ambient light sensing capabilities. It features low-power operation, 16-bit resolution, and programmable gain & integration time, meeting MSL Grade 3. The supply voltage ranges from 2.6-3.6V (typical 3.3V), operating temperature from -30~+70℃, active current from 300-350μA, and sleep current as low as 1-25μA. It communicates via an I2C serial interface (supporting two selectable addresses) and outputs five-channel light signal data (R/G/B/C/IR) with peak sensitivity wavelengths of 630nm (R), 550nm (G), 480nm (B), 590nm (C), and 870nm (IR). The peak soldering temperature is 260℃, with a recommended 240℃/10s.
Ideal for brightness sensing, color temperature detection, notebooks, handheld devices, scanners, etc.
Color Temperature and Ambient Light Sensing.
Low Power Management .
16 Bit resolution
Programmable Gain & Integration Time.
Moisture sensitivity level（MSL） : 4-5 levels
Brightness Sensing
Color Temperature Sensing
Notebook
Handheld device
Scanner
